Up to 4 Hours Fire Resistance
Auto Activation
Fire Proof Rolling Shutter
Bangladesh
Expert Automation BD supplies and installs certified Fire Proof Rolling Shutters that act as a critical fire barrier — automatically sealing openings to stop fire spread, protect lives, and meet Bangladesh building safety regulations.
- BS 476 Part 22 : 1987 Compliant
- Up to 4 Hours Fire Rating
- Auto Thermal / Fusible Link Activation
- Gravity Fail-Safe Mechanism
- Factory, Hospital & Mall Approved
- Free Site Survey
What Is a Fire Proof Rolling Shutter?
A Fire Proof Rolling Shutter (also called a Fire Rated Rolling Shutter or Fire Barrier Shutter) is a certified fire safety system designed to automatically close and contain fire within a compartment during a fire emergency.
Unlike standard rolling shutters, fire proof shutters are built with fire-resistant steel curtains and are tested and certified to withstand fire for 60 minutes up to 4 hours (E60-E240 ratings). They activate automatically via thermal sensors or fusible link mechanisms – requiring no human intervention.
Expert Automation BD supplies and installs BS 476: Part 22 : 1987 certified fire proof rolling shutters across Bangladesh for factories, hospitals, shopping malls, warehouses, and commercial buildings.
Available Fire Rating Classes
Fire proof rolling shutters are classified by how long they can withstand fire while maintaining integrity and stability.
Key Features of Our Fire Proof Rolling Shutters
Engineered to the highest international fire safety standards, built for Bangladesh’s industrial and commercial environments.
Automatic Fire Activation
Activates instantly via thermal sensor or fusible link – no manual operation needed during a fire emergency.
BS 476 : Part 22 : 1987 Certified
Tested and certified to international fire resistance standards for up to 4 hours of integrity and stability.
Gravity Fail-Safe Mechanism
Closes automatically under gravity if power fails – ensuring the shutter always protects during emergencies.
Fire-Resistant Steel Curtain
Made from heavy-gauge galvanized or mild steel specifically selected for high fire resistance performance.
Smoke Sealing
Integrated perimeter smoke seals prevent smoke from passing through, providing life-safety protection in escape routes.
Motorized + Manual Release
Motorized operation for routine use with automatic gravity drop and manual release override for emergency use.
Custom Sizes Available
Manufactured to exact opening dimensions – suitable for small doorways to large industrial bay openings.
Regulatory Compliance
Meets Bangladesh National Building Code (BNBC) and fire authority requirements for commercial and industrial buildings.
How Does a Fire Proof Rolling Shutter Activate?
Fire proof shutters operate automatically during fire events through two proven activation methods:
Thermal Sensor Activation
A heat detector monitors ambient temperature. When the temperature reaches a preset threshold (typically 68C-93C), the sensor triggers the motor control unit, releasing the shutter to close under gravity or motor drive.
Fusible Link Activation
A fusible link is a mechanical device that melts at a specific temperature (typically 72C). When it melts, it releases the shutter hold-open mechanism, causing the shutter to descend by gravity – functioning even during power failure.
Fire Starts
Fire or smoke detected in the building area.
Sensor Triggers
Thermal sensor or fusible link activates at heat threshold.
Signal Sent
Activation signal released to motor control unit.
Shutter Descends
Shutter closes fully – sealing the opening.
Area Contained
Fire compartment sealed – spread stopped.
Technical Specifications
All fire proof rolling shutters are manufactured to meet international standards and certified before installation.
| Parameter | Specification |
|---|---|
| Fire Rating | E60 / E90 / E120 / E180 / E240 (up to 4 hours) |
| Compliance Standard | BS 476: Part 22 : 1987 (Fire resistance) |
| Curtain Material | Heavy-gauge Galvanized Steel / Mild Steel |
| Curtain Thickness | 1.0 mm – 3.0 mm (as per fire rating) |
| Activation System | Thermal Sensor / Fusible Link |
| Operation Mode | Motorized with gravity fail-safe auto-close |
| Motor Supply | 1-Phase 220V / 3-Phase 420V |
| Motor Power | 250W – 750W (as per shutter size) |
| Opening Speed | 5 – 15 m/min (motorized) |
| Smoke Seal | Integrated perimeter smoke seals (standard) |
| Manual Release | Emergency manual release handle (standard) |
| Max Width (Single Motor) | Up to 6,000 mm |
| Max Height | Custom as required |
| Control Panel | Fire alarm panel integration available |
| Finish | Galvanized / Powder-coated paint |
Where Are Fire Proof Rolling Shutters Mandatory?
Bangladesh National Building Code (BNBC) and fire authority regulations require fire-rated shutters in high-risk and public buildings.
Factories & Industrial Plants
Hospitals & Healthcare
Shopping Malls & Markets
High-Rise Commercial Buildings
Warehouses & Logistics
Power Plants & Substations
Schools & Universities
Hotels & Resorts
Important: Fire proof rolling shutters must be installed by certified professionals and must form part of a compliant fire safety strategy approved by the Bangladesh Fire Service and Civil Defence (BFSCD).
Fire Proof vs. Standard Rolling Shutter
Understanding the key differences helps you make the right choice for your building’s safety requirements.
| Feature | Fire Proof Shutter | Standard Shutter |
|---|---|---|
| Fire Resistance | Up to 4 hours | None |
| Auto Activation | Yes – thermal/fusible | No |
| BS 476 Certification | Yes – certified | No |
| Gravity Fail-Safe | Standard feature | Not applicable |
| Smoke Sealing | Integrated seals | No seal |
| Regulatory Compliance | BNBC / BFSCD compliant | Not applicable |
| Life Safety Role | Critical – mandatory | Security only |
| Fire Alarm Integration | Available | No |
Why Expert Automation BD for Fire Proof Rolling Shutters?
Years of Experience
Over a decade of fire safety and automation expertise across Bangladesh.
Certified Products Installed
All shutters carry BS 476 certifications with full technical documentation.
Professional Installation
Skilled team ensures correct, compliant installation and full commissioning.
After-Sales Service
Annual maintenance, servicing, and emergency repair support available.
Frequently Asked Questions
Everything you need to know about fire proof rolling shutters in Bangladesh.
Fire Proof Rolling Shutter Installation Process in Bangladesh
Installing a fire proof rolling shutter requires careful planning, precise measurement, and certified expertise. At Expert Automation BD, our trained engineers follow a rigorous installation process to ensure your fire proof rolling shutter performs flawlessly when it matters most.
Step-by-Step Installation Guide
Our fire proof rolling shutter installation begins with a thorough site survey. Our technical team visits your premises, assesses the opening dimensions, evaluates the structural integrity of the surrounding wall or frame, and determines the most suitable mounting method. This free site survey ensures accurate quotation and eliminates surprises during installation.
Once the survey is complete, we custom-fabricate the fire proof rolling shutter to match your exact specifications. Our shutters are manufactured using galvanised steel slats or stainless steel, depending on the fire resistance rating required. Each slat is interlocked to create a continuous barrier that prevents the spread of fire and smoke.
The installation team mounts the guide channels on both sides of the opening, ensuring perfectly plumb alignment. The barrel assembly — housing the coiled shutter curtain — is then secured above the opening. Electrical wiring for the automatic activation system is run in conduit and connected to your building’s fire alarm panel, ensuring the fire proof rolling shutter activates the moment smoke or heat is detected.
After installation, every fire proof rolling shutter undergoes a comprehensive testing procedure. We verify the automatic drop test, manual override operation, and integration with the fire alarm system. You receive a handover certificate, user manual, and maintenance schedule.
Post-Installation Support and Maintenance
A fire proof rolling shutter is a life-safety device — regular maintenance is not optional. Expert Automation BD offers annual maintenance contracts (AMC) to keep your shutters in peak condition. Our service includes lubricating moving parts, inspecting the slat curtain for damage, testing the automatic activation mechanism, checking electrical connections, and issuing a maintenance compliance certificate for your fire safety audit records.
Types of Fire Proof Rolling Shutters Available
Expert Automation BD supplies and installs several types of fire proof rolling shutters to meet diverse architectural and compliance requirements across Bangladesh.
Steel Fire Rated Rolling Shutters
The most common type of fire proof rolling shutter, steel fire rated models use galvanised or mild steel slats with mineral wool insulation. Available in fire resistance ratings from 60 minutes up to 240 minutes (4 hours), these shutters are ideal for industrial warehouses, commercial buildings, shopping malls, and manufacturing facilities.
Insulated Fire Proof Rolling Shutters
Where temperature control and fire resistance are both required, insulated fire proof rolling shutters offer double protection. The foam-injected or mineral-wool-filled slats limit both flame spread and radiant heat transfer, protecting adjacent occupants and equipment. These are commonly specified for hospitals, data centres, and pharmaceutical storage areas in Bangladesh.
Stainless Steel Fire Shutters
For clean-room environments, food processing facilities, or areas requiring corrosion resistance, stainless steel fire proof rolling shutters provide the same fire resistance as standard models while resisting rust, chemicals, and moisture. Available in Grade 304 and Grade 316 stainless steel.
Perforated Fire Rated Shutters
When visual transparency is required while maintaining fire protection — such as in retail shopfronts or lobby areas — perforated fire proof rolling shutters allow visibility during normal operation while closing completely to form a solid fire barrier when activated.
Where Are Fire Proof Rolling Shutters Used in Bangladesh?
Fire proof rolling shutters are mandatory in many building types under Bangladesh National Building Code (BNBC) and fire safety regulations. Expert Automation BD installs fire proof rolling shutters across a wide range of applications throughout Dhaka, Chittagong, Sylhet, Rajshahi, and beyond.
Garment Factories and Industrial Units
Bangladesh’s ready-made garment (RMG) sector requires strict fire safety compliance. Fire proof rolling shutters compartmentalise factory floors, protect stairwells and lift shafts, and secure chemical storage areas — helping factories meet Accord, Alliance, and BGMEA fire safety audit requirements.
Commercial Shopping Malls and Retail Outlets
Modern shopping centres in Dhaka and Chittagong install fire proof rolling shutters at every shopfront to contain fires within individual units and protect common areas. Our fire proof rolling shutters can be coordinated with facade designs for a seamless aesthetic.
Hospitals and Healthcare Facilities
Patient safety makes fire compartmentalisation critical in hospitals. Fire proof rolling shutters protect operating theatre corridors, pharmacy storage rooms, medical gas storage areas, and basement car parks, ensuring patients and staff can evacuate safely.
Hotels and Hospitality Properties
Five-star hotels and convention centres throughout Bangladesh specify fire proof rolling shutters for kitchen service corridors, linen storage, basement areas, and plant rooms. Our shutters integrate with building management systems (BMS) for centralised fire safety monitoring.
Fire Proof Rolling Shutter Compliance and Certifications
Choosing a certified fire proof rolling shutter is essential for regulatory compliance and insurance validity. Expert Automation BD supplies only shutters that meet recognised international fire testing standards, ensuring your building passes fire safety inspections and audits.
BS 476 Fire Testing Standard
Our fire proof rolling shutters are tested and certified to BS 476 Parts 20, 21, and 22 — the British Standard for fire tests on building materials and structures. This internationally recognised standard verifies that the shutter maintains its integrity, insulation, and load-bearing capacity under fire conditions for the stated duration (60, 120, or 240 minutes).
Bangladesh National Building Code (BNBC) Compliance
The Bangladesh National Building Code requires fire separation between occupancies and compartmentalisation in multi-storey buildings. Our fire proof rolling shutters help architects and developers meet these mandatory requirements. We provide all necessary documentation for building permit applications and fire safety certificates issued by Bangladesh Fire Service and Civil Defence (BFSCD).
Why Certification Matters
An uncertified fire shutter is a liability risk. In the event of a fire, insurance claims may be denied if non-compliant shutters are installed. Certified fire proof rolling shutters from Expert Automation BD come with test certificates, installation compliance certificates, and maintenance logs — everything you need for full regulatory compliance and peace of mind.
Contact Expert Automation BD for a Free Consultation
Our fire safety specialists are ready to advise you on the right fire proof rolling shutter specification for your project. Whether you are planning a new building, renovating an existing structure, or upgrading your fire safety systems, we offer a free site survey and no-obligation quotation anywhere in Bangladesh. Reach out to our team today to protect your property, assets, and most importantly, your people.
Why Choose Expert Automation BD for Fire Proof Rolling Shutters?
Expert Automation BD is Bangladesh’s trusted specialist for fire proof rolling shutter supply, installation, and maintenance. With years of experience serving factories, commercial buildings, hospitals, and hotels across Dhaka, Chittagong, Gazipur, Narayanganj, and all major cities, we bring unmatched expertise to every fire safety project.
Our fire proof rolling shutters are backed by manufacturer warranties, full installation certificates, and ongoing after-sales support. Every project is handled by trained fire safety engineers — not general contractors. We use premium grade materials, follow international installation best practices, and ensure your fire proof rolling shutter system integrates seamlessly with your existing fire detection and alarm infrastructure. Choose Expert Automation BD for reliable fire protection that meets every compliance requirement in Bangladesh.
Fire Safety Standards & Resources
Our fire proof rolling shutters comply with internationally recognised fire safety standards. Learn more:
